Construction Site Logistics and Layout Planning with SketchUp
In this tutorial I cover various approaches for construction site logistics planning in SketchUp. This begins with importing an accurate geolocated site, constructing a rough building model from a plan, and then laying out the construction site with pre-made components from the 3D Warehouse. This is then followed with crane location planning.
As I mention in the video, the goal here was to use the 3D environment for rough (but realistic) logistics planning. Adjust the techniques as needed for your projects. Also, for more documentation options, check out SketchUp's LayOut software.
The Turner Construction Logistics Collection that I mention in the video can be found here:
https://3dwarehouse.sketchup.com/coll...
For more on what you can do with SketchUp, check out my site https://sketchupfordesign.com and my book "Architectural Design with SketchUp".
Chapters:
0:00 Introduction
0:27 Adding the site / geo-locating the model
4:13 Creating the building model from a plan
13:35 Adding site elements from the 3D Warehouse
17:24 Adding flat illustrative elements
19:42 Annotating with text
20:57 Adding crane locations using diagrams
28:15 Finishing the documentation
