Title: - ANFIS BASED SUPERCONDUCTING MAGNETIC ENERGY STORAGE SYSTEM (SMES) FOR A GRID CONNECTED WIND ENERGY CONVERSION SYSTEM IN A DISTRIBUTION NETWORK
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------
Implementation Plan:
----------------------
Step 1: Initially we design the Simulink model based on a grid-connected doubly fed induction generator (DFIG). Here we used the IEEE 33 bus system.
Step 2: Next we perform the output power fluctuation of the DFIG wind turbine effectively during normal operation.
Step 3: Next we reduce the overvoltage in the dc link during faults.
Step 4: Then we perform the overcurrent in both stator and rotor during the faults. This optimization problem is solved by a particle swarm optimization (PSO).
Step 5: Finally, This work is evaluated with the performance metrics,
• Number of particles in the PSO vs. power loss
• Number of particles in the PSO vs. voltage stability
• Number of particles in the PSO vs. voltage deviations
• Number of particles in the PSO vs. forecasting error
• Iteration time vs. fitness value
===========================================================================================================================================================
Software Requirement:
-----------------------
Software Requirement:
-----------------------
1. Tool: Matlab-R2020a/Simulink
2. Operating System: Windows 10 (64-bit)
=============================================================
Install the required software...
Copy the zip file and paste to the D or E drive and Extract the zip file.
Copy the folder "ANFIS BASED SUPERCONDUCTING MAGNETIC ENERGY STORAGE SYSTEM (SMES)" under the code folder and Paste into any drive.
Note: Don't Delete any file or folders project contains...
Then Launch matlab IDE.
Next copy the source code location (Note: Use the source code location avoids space). Then paste the source code location into matlab address location. After paste, press the enter key.
