Point Clouds in SketchUp: 3D Modeling Approaches (Video 5/6)
This series of videos shows how you can use Trimble's point clouds extension "Scan Essentials" to model accurate 3D geometry in SketchUp. The rest of the videos can be found here:
First Steps with Scan Essentials (Video 1/6) - • Point Clouds in SketchUp: First Steps...
Trimble Realworks Processing (Video 2/6) - • Point Clouds in SketchUp: Trimble Rea...
Point Cloud Manager Dialog (Video 3/6) - • Point Clouds in SketchUp: Point Cloud...
Using Clipping Boxes (Video 4/6) - • Point Clouds in SketchUp: Using Clipp...
3D Modeling Approaches (Video 5/6) - • Point Clouds in SketchUp: 3D Modeling...
The Ground Mesh Tool (Video 6/6) - • Point Clouds in SketchUp: The Ground ...
In this video I cover several 3D modeling approaches that you can use (often interchangeably) while working with point clouds.
Find out more about the Scan Essentials extension at: https://extensions.sketchup.com/exten...
For more on what you can do with SketchUp, check out my book "Architectural Design with SketchUp" and my website: https://sketchupfordesign.com
Chapters:
0:00 Introduction
0:48 Drawing directly on the point cloud
2:27 Drawing in SketchUp and moving onto the cloud
3:58 Extruding drawn geometry
5:17 Verifying drawing accuracy with the inspection map
6:33 Drawing with pre-made 3D shapes
9:48 Drawing construction geometry for later modeling
