Basics of Assembly in Abaqus: How to Move, Rotate, and Insert Components
The assembly module in Abaqus is much more limited than the Solidworks environment and you might not have as many options to control your model. However, there are enough to create the geometry which requires you t=to understand the available features. In this video, we explain the basics of the assembly module in Abaqus that include features such as translation, rotation, applying constraint, and etc.
The video contents are as follows:
0:00 Introduction
0:18 Dependent and independent in Abaqus assembly
0:36 Translate a component
1:19 Rotate a component
1:49 Creating multiple components in a linear pattern
2:07 Creating multiple components in a circular pattern
