AutoCAD Tips & Tricks | How to Use WIPEOUT Command in AutoCAD for temporarily hiding an object | WIPEOUT & WIPEOUT FRAME

To conceal a region in a design, use AutoCAD's WIPEOUT command. The WIPEOUT command can be used whenever the drawing backdrop contains a lot of intricate features that need to be hidden. When only a small area of a drawing is of interest, it can also be employed.

By applying the backdrop color to a polygonal area, the WIPEOUT command masks the items in a chosen region. A drawing appears blank when a section or region has been "wiped out."

A frame that serves as the definition of this erased region is editable at any time, allowing you to efficiently increase or decrease the area.
