Design an electronics circuit in Fritzing - Creating a breadboard layout and schematic diagram
This video explains about designing electronics using Fritzing. This video explains about creating a schematic diagram and a breadboard layout. Then in subsequent videos this will be made into a printed circuit board (PCB) in Fritzing to make a Raspberry Pi HAT which then has the electronic components soldered to is creating a complete solution.
This is based around Fritzing which is an electronic circuit designer which is good for creating visual images of breadboard designs. It is one of the few tools that does so and so is a popular tool for that alone. I have used it for many of my projects on http://www.penguintutor.com
The circuit being designed is a Raspberry Pi Christmas House building designed for an outdoor model railway, which is explained in this video: • Raspberry Pi Christmas House and NeoP...
The circuit uses a number of different LEDs, a NeoPixel, and a smoke generator. This includes several MOSFETs and resistors used to increase the signal from the Raspberry Pi GPIO ports.
The Adrafruit Fritzing library is available from: https://github.com/adafruit/Fritzing-...
The N-Channel MOSFET Fritzing library (2N7000) is available from; https://forum.fritzing.org/uploads/sh...
For more details see: http://www.penguintutor.com/electroni...
Chapters:
00:00 Introduction to the Raspbery Pi Christmas House
00:55 Introduction to Fritzing electronics program
01:51 Fritzing breadboard view
02:43 Fritzing schematic diagram view
06:06 Laying out the components
13:40 Using AdaFruit library NeoPixel
26:01 Adding a smoke generator
42:06 Finished breadboard electronic circuit
Please subscribe to find out about future videos. Thanks!
