MQ9 Gas sensor interfacing with LPC2138 | Simulation | Methane, Carbon monoxide
MQ9 Gas sensor interfacing with PIC16F628A | Simulation | Methane(CH4), Carbon monoxide (CO)
-----------------------------------------------------------------------------------------------------------------------------------------------------------------
--------------------------
Features of MQ9 Sensor
--------------------------
1] Suitable for home or factory gas leakage monitoring devices.
2] Have better sensitivity to Carbon Monoxide, Methane and LPG Gas.
3] High quality dual-panel design, with power indicator and TTL signal output instructions.
4] DO switching signal (TTL) output and AO analog signal output.
5] TTL output valid signal is low. (When the output low signal is on, it can be directly connected micro-controller or relay module.)
6] Analog output voltage: the higher concentration, the higher voltage.
7] Four screw holes, easy positioning.
8] Long life and stability, quick response and resume
--------------------------
