Hybrid Desktop PC Server Build | Part 3 - Server build | dual system Phanteks Evolv X
This video is the 3rd and last part in the hybrid desktop pc / server build series. In part 3, I'll show you the parts we chose for the server side of this build and the process we went through. This server is built in the dual system Phanteks Evolv X case with the Phanteks Revolt PSU. There were some quirks in building the server in the Phanteks Evolv X case and we'll discuss some of those details in this video. Below are timestamps you can use to skip to any section of particular interest.
If you missed the previous parts in this series, check them out here:
Part 1: Introduction to the hybrid desktop pc server build • Hybrid Desktop PC Server Build | Part...
Part 2: Hybrid desktop PC server build - the PC build • Hybrid Desktop PC Server Build | Part...
Timestamps:
0:59 - Overview of the server components selected for this build
5:42 - Adding 3rd front case fan for cooling HDDs in PSU chamber
13:06 - Installing the PCIe riser cable for the LSI HBA controller
20:35 - Installing Mini-ITX board inside the Phanteks Evolv X
28:33 - Hooking up ATX power to the mini-ITX board
31:48 - Installing LSI 9201-8i HBA SAS controller in vertical PCIe slot
32:41 - Explaining the HDD setup and forced to do proper cable management
44:37 - Explaining the MikroTik CRS305-1G-4S+IN 10Gb networks swtich
52:18 - Explaining the dual system PSU Phanteks Revolt
55:24 - Showing the MikroTik CRS305-1G-4S+IN installed
57:20 - Explaining the fan control hub and chassis cooling for dual system setup
1:05:47 - Explaining demo setup of hybrid desktop PC / server build - explaining setup
1:08:20 - Power on desktop PC demonstration with power consumption monitoring
1:10:36 - Power on server demonstration with power consumption monitoring
1:16:18 - Measuring noise levels
1:20:34 - Wrap up
Parts used in this build (with affiliate links):
CPU/Motherboard combo: Supermicro X10SDV-TLN4F (https://ebay.us/s7M3kH)
Case: Phanteks Evolv X (https://ebay.us/HLKfPT)
Phanteks HDD mounting brackets: PH-HDDKT_03 (https://ebay.us/Bu40nq)
Phanteks Mini-ITX bracket: PH-ITXKT_R01 (https://ebay.us/q3018Q)
Phanteks PCIe Riser cable: PH-CBRS_PR60 (https://ebay.us/2jPwGd)
Phanteks 140mm case fan: (https://ebay.us/vaDWRP)
Power Supply: Phanteks Revolt X 1200W PH-P1200PS (https://ebay.us/KtWPCR)
SAS Controller: LSI 9201-8i (At ART of SERVER store: https://ebay.to/3tm34IJ)
SAS Cabling: SFF8087-4xSFF8482 (At ART of SERVER store: https://ebay.us/uC01oF)
Storage: HGST 3.5" SAS drives (https://ebay.us/5bIvKG)
Storage: Intel Optane M.2 118GB SSD (https://ebay.us/RBmN0W)
Network: Mikrotik CRS305-1G-4S+IN 10Gb network switch (https://ebay.us/LxxwwI)
