SkyConnect in ZHA & Zigbee2MQTT - HA OS and Docker
SkyConnect is awesome Zigbee (Thread & Matter) compatible device that can bring stability to your Zigbee network. Today we will install SkyConnect with HA OS and Docker and test it with both ZHA and Zigbee2MQTT.
We will do all of that on Synology because if it works on it, it should work anywhere.
And as a bonus, we will look at USB drivers for Synology DSM 7.0 and DSM 7.1 - new GitHub repository since jadahl.com is not available anymore.
00:00 - Intro
00:27 - Different installation types
01:07 - Synology VM USB passthrough
02:11 - SkyConnect with ZHA
03:39 - SkyConnect with Zigbee2MQTT
07:59 - USB drivers for Synology
09:27 - ZHA in Docker
22:26 - Zigbee2MQTT Docker specifics
Zigbee2MQTT AddOn Installation guide repository link: https://github.com/zigbee2mqtt/hassio...
AddOn repository link: https://github.com/zigbee2mqtt/hassio...
Zigbee2MQTT specific setting:
serial:
port: /dev/ttyACM0
adapter: ezsp
Putty: https://www.putty.org/
Synology USB drivers: https://github.com/robertklep/dsm7-us...
Processor architecture: https://kb.synology.com/en-me/DSM/tut...
Copy drivers: cp *.ko /lib/modules
Copy script: cp usb-serial-drivers.sh /usr/local/etc/rc.d
Change permission: chmod +x /usr/local/etc/rc.d/usb-serial-drivers.sh
Start the script: /usr/local/etc/rc.d/usb-serial-drivers.sh start
Time Zones: https://en.wikipedia.org/wiki/List_of...
Docker command: sudo docker run -d --name homeassistant --privileged --restart=unless-stopped -e TZ=Europe/Zagreb -v /volume1/docker/homeassistant:/config --network=host --device /dev/ttyUSB0:/dev/ttyUSB0 ghcr.io/home-assistant/home-assistant:stable
Don't forget to give this video thumb up if you liked it, subscribe if you still haven't and I'll see you next time!
Have fun!
