DIY Full Bridge Rectifier AC to DC Kit 1N4007 - $2 Aliexpress Circuit
In this video I build a cheap full bright rectifier kit I got from Aliexpress. I learnt loads doing this. I'm getting some soldering experience under my belt which I greatly need. I got a lot more videos like this coming so if you enjoy it, subscribe.
Aliexpress Kit Link: https://www.aliexpress.com/item/33046...
Amazon Kit Link: https://amzn.to/3vpur6P
1N4007 Diy Kit IN4007 Bridge Rectifier AC DC Converter Full Wave Rectifier PCB Board KIT Parts Electronic Suite
On-board level conversion chip for 5V/3.3V MCU.
Maximum output current: 1A
Input communication: 3-18V
AC DC output: AC to DC
PCB size: Approx. 3x2.8x0.4cm / 1.18x1.10x0.16inch
Timestamps
0:00 Intro
1:35 Input Problem
3:45 Soldering
7:28 Simulation
13:09 Real Test
Hi, I'm Hamed, an Electrical & Electronics Engineering Student in Leeds, UK.
Visit my website at www.hamed.engineer
If you have any questions you can email me at [email protected] or just comment below.
